IMPORTANT
Visually check all inlet pipes supplied by the installer and/or blow
them out using compressed air to clean out any dirt or debris
(threads or other foreign matter) before installing a service line.
These particles will clog the gas holes when gas pressure is applied.
Compounds used in appliance pipe threaded joints shall be resistant
to the action of GN and LPG gas and shall provide a gas tight seal to
prevent leakage.
When installing the pressure regulator remember that it can support
1/2 PSI (3.45k Pa).
When installing LPG, you have high source pressures ranging from
20 PSI (127.89kPa) to 100 PSI (689.48 kPa). If the LPG tank’s high
pressure gas line is directly connected to a unit without the proper
reduction regulator, it will rupture the diaphragm in the valve,
making it useless.
Any adjustment to the regulator should be done only by qualied
and licensed personnel with the appropriate calibrated test
equipment. Connections must be made by a licensed and
qualied contractor.
Air vent cap.
Direction of
the arrow at
the bottom of
the regulator.
Warranty/Tech Support 800•722•6075
Service, Installation
& Care Manual
11
At the bottom of the regulator body there is a gas direction arrow to minimize
installation error. This arrow should point to the device’s direction of entry into the
equipment.
The blue air vent cap on the top of the regulator is part of the regulator and should not
be removed.
