800•722•6075 Warranty/Tech Support
Service, Installation
& Care Manual
16
02. EQUIPMENT INSTALLATION
2.11 Flue Riser Assembly
2.12 First Time Use
To assemble the ue riser and shelf on the range it is necessary to follow the following
steps:
1. Fit the ue riser on the back (1) to the range (2).
2. Use four screws with four at washers to x the internal part of the ue riser on the side
of the equipment (two screws and two washers on each side), as shown in image 1.
Note: For 60" models, you must also perform the xation in the central part of the ue
riser with 2 screws (6), according to image 2.
3. Finally, t the shelf (5) to the ue riser.
To protect the equipment against possible damage caused by shock or rocking from
transportation, burners, grids and grills are secured by plastic straps. The sides, and the
waste tray have a protective PVC lm. Remove any plastics, straps, or protective lm from
the equipment before operating the equipment.
Before using the equipment for the rst time you should clean it with a sponge, mild soap
and water. Only then will the equipment be ready for use.
