4
Mounting Port: Port for mounting bracket
The flashing status of the Power light and Network light are shown in the following table.
Light Flashing Status Description
Power light off The power don't work properly.
on The power supply works fine.
Network light off No Wireless connection
Slow Flash once per second Wireless connection
Flashing every 0.4 seconds WPS is connecting
Flashing every 0.2 seconds EZLink takes effect
Constant for 3 seconds one time Reset to take effect
1.5 Hardware Installation
Step 1: Screw the mount on the wall with the two screws provided.
Step2: Loosen the thumb screws to adjust the mount to the desired position. Once the position is set,
tighten the screws securely.
