Foscam SD2 User Manual

20
Section 4 Cruise / Preset settings
Cruise Settings
The default cruise tracks have two types: Vertical and Horizontal.
Vertical: The camera will rotate from up to down.
Horizontal: The camera will rotate from left to right.
: Start cruise. : Stop cruise.
If you want to define or change the cruise trace, please go to Settings PTZ Preset Settings panel.
How to do cruise?
Firstly: Select one track in the track dropdown list.
Secondly: Click Start cruise button, the camera will cruise following the predefined path.
Thirdly: Click stop button and finish cruising.
Preset settings
IPCam supports 16 preset positions, which is considered enough for DIY home & small business
surveillance market
The default preset position is Topmost, Bottom most, Left most, right most, you can add other preset
positions.
Add Click this icon to save the position you need the camera to remember
Select one of these.

Foscam SD2 Specifications

General

Type	IP security camera
Antenna type	External
Certification	FCC, CE, RoHS
Day/night mode	Yes
Placement supported	Indoor & outdoor
Connectivity technology	Wireless
Audio system	2-way
Bluetooth	-
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wi-Fi data rate (max)	450 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IP, TCP, UDP, HTTP, HTTPS, DHCP, SMTP, FTP, RTSP
Minimum illumination	0 lx
Optical zoom	4 x
Number of lenses	1
Focal length range	2.8 - 12 mm
Maximum aperture number	3
Minimum aperture number	1.7
Form factor	Dome
Mounting type	Wall
Product color	White
International Protection (IP) code	IP66
Sensor type	CMOS
Optical sensor size	1/2.9 \
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	240p, 480p, 720p, 1080p
Video formats supported	H.264
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Supported graphics resolutions	320 x 240, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
LED type	IR
Night vision distance	50 m
Number of illumination LEDs	6
Security algorithms	WPA, WPA2
Alert notification type	E-mail
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Mobile operating systems supported	Android, iOS
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	0 - 90 %
Operating relative humidity (H-H)	20 - 85 %
Power consumption	200 mA
Power consumption (max)	20 W
Harmonized System (HS) code	85258900

Weight and Dimensions

Width	111 mm
Length	180 mm
Weight	1000 g
