Foscam SD2 User Manual

110
More FAQs are available here:
https://www.foscam.com/faqs/index.html
5.2 Default Parameters
Default network parameters
IP address: obtain dynamically
Subnet mask: obtain dynamically
Gateway: obtain dynamically
Username and password
Default admin username: admin with a random password
5.3 Specification
Image Sensor
Sensor
High Definition Color CMOS Sensor
Display Resolution
2.0MegaPixels
Min. Illumination
0 Lux (With IR Illuminator)
Lens
Lens Type
Glass Lens
Focal Length
f: 2.8-12mm
Aperture
F1.7~F3.0
Angle of View
Horizontal: 99.6°~30.6° Diagonal : 117.59°~35.1°
Video
Image Compression
H.264
Image Frame Rate
25fps（1080P）/15fps（720P）/, downward adjustable
Resolution
1080P(1920x1080),720P(1280 x 720), VGA(640 x 480),
QVGA(320 x 240)
Stream
Dual stream
Image Adjustment
The hue, brightness, contrast, saturation, sharpness are
adjustable
Flip Image
flip and mirror
Infrared Mode
Automatic and manual
IR Range
6pcs Infrared-LEDs, night vision range up to 50 metres
Network
Ethernet
One 10/100Mbps RJ45 port
Remote Access
P2P
Data Rate
IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.).
IEEE802.11ac: 433Mbps(Max.).
Wireless Standard
2.4G/5G dual band, IEEE802.11b/g/n/ac
Network Protocol
IP、TCP、UDP、HTTP、HTTPS、SMTP、FTP、DHCP、
RTSP、ONVIF
System
Requirements
Operating System
Microsoft Windows XP, 7, 8;Mac OS;iOS、Android

Foscam SD2 Specifications

General

Type	IP security camera
Antenna type	External
Certification	FCC, CE, RoHS
Day/night mode	Yes
Placement supported	Indoor & outdoor
Connectivity technology	Wireless
Audio system	2-way
Bluetooth	-
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wi-Fi data rate (max)	450 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IP, TCP, UDP, HTTP, HTTPS, DHCP, SMTP, FTP, RTSP
Minimum illumination	0 lx
Optical zoom	4 x
Number of lenses	1
Focal length range	2.8 - 12 mm
Maximum aperture number	3
Minimum aperture number	1.7
Form factor	Dome
Mounting type	Wall
Product color	White
International Protection (IP) code	IP66
Sensor type	CMOS
Optical sensor size	1/2.9 \
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	240p, 480p, 720p, 1080p
Video formats supported	H.264
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Supported graphics resolutions	320 x 240, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
LED type	IR
Night vision distance	50 m
Number of illumination LEDs	6
Security algorithms	WPA, WPA2
Alert notification type	E-mail
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Mobile operating systems supported	Android, iOS
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	0 - 90 %
Operating relative humidity (H-H)	20 - 85 %
Power consumption	200 mA
Power consumption (max)	20 W
Harmonized System (HS) code	85258900

Weight and Dimensions

Width	111 mm
Length	180 mm
Weight	1000 g
