67
Sound ----- Click the icon then you will hear sound captured by the camera's built-in microphone. You
may need to plug in earphones or enable the computer speakers to hear from the camera's microphone.
Make sure the camera supports audio. Click again and stop audio.
Talk ----- Click the button, then talk to the microphone that connected with PC, people around the
camera can here you voice. Click the icon again and stop talking.
Section4 The number of split-screen
Click this button to select the number of split-screen on one page.
The client can monitor many cameras at one page, here you can choose the display number. The
maximum number is 16.
Section5 Live Cruise / Close All / Full Screen / Hide Bar
Live Cruise ----- Click this button to Live Cruise, you can click button to add a loop page for
live
Cruise or click button to reduce the loop page for live Cruise.
Close All ----- Click this button to close all the cameras
Full Screen ----- Click this button to enter full screen, Click this button to enter full screen, then
click to exit full screen.
Hide Bar ----- Click this button, Hide and show Pan / Tilt control Bar
Section6 Cruise / Focus buttons / Pan / Tilt control / Zoom buttons/ Preset
Cruise Settings
The default cruise tracks have two types: Vertical and Horizontal.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Foscam SD2 and is the answer not in the manual?

Foscam SD2 Specifications

General IconGeneral
TypeIP security camera
Antenna typeExternal
CertificationFCC, CE, RoHS
Day/night modeYes
Placement supportedIndoor & outdoor
Connectivity technologyWireless
Audio system2-way
Bluetooth-
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wi-Fi data rate (max)450 Mbit/s
Ethernet interface typeFast Ethernet
Supported network protocolsIP, TCP, UDP, HTTP, HTTPS, DHCP, SMTP, FTP, RTSP
Minimum illumination0 lx
Optical zoom4 x
Number of lenses1
Focal length range2.8 - 12 mm
Maximum aperture number3
Minimum aperture number1.7
Form factorDome
Mounting typeWall
Product colorWhite
International Protection (IP) codeIP66
Sensor typeCMOS
Optical sensor size1/2.9 \
Total megapixels2 MP
Maximum resolution1920 x 1080 pixels
Supported video modes240p, 480p, 720p, 1080p
Video formats supportedH.264
Image quality adjustmentBrightness, Contrast, Saturation, Sharpness
Supported graphics resolutions320 x 240, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
LED typeIR
Night vision distance50 m
Number of illumination LEDs6
Security algorithmsWPA, WPA2
Alert notification typeE-mail
Built-in HDDNo
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size128 GB
Mobile operating systems supportedAndroid, iOS
Cables includedLAN (RJ-45)
Storage temperature (T-T)-20 - 50 °C
Operating temperature (T-T)-20 - 60 °C
Storage relative humidity (H-H)0 - 90 %
Operating relative humidity (H-H)20 - 85 %
Power consumption200 mA
Power consumption (max)20 W
Harmonized System (HS) code85258900
Weight and Dimensions IconWeight and Dimensions
Width111 mm
Length180 mm
Weight1000 g
