Calibration
2244
TEST DISC
An Enhanced CD-ROM is supplied with your FAP V1 to aid in calibration of surround speaker SPL levels and
verification of performance.
Surround channels described over the next few pages are referred to in these abbreviations:
CF – Center Front
RF – Right Front
LF – Left Front
RS – Right Side
LS – Left Side
RB – Right Back
LB – Left Back
CB – Center Back
RB/S – Right Back and Right Side
LB/S – Left Back and Left Side
SUB – Subwoofer
Included in your test disc are the following tools:
• Channel identification tracks
• Full bandwidth pink noise test tones for each channel
• 100Hz, 1kHz, 5kHz test tones for CF, RF, RB, CB,
LB, LF
• 50Hz test tone for CF
• Owner’s manual in .pdf format (Adobe Acrobat needed
to open file)
Test CD Tracks:
1. Channel Identification 5 sec.
Duration each location
starting at CF
2. Noise Sequencer 1 sec.
Duration each location
starting at CF
3. Noise Sequencer 5 sec.
Duration each location
starting at CF
4. CF Pink Noise (1:00)
5. RF Pink Noise (1:00)
6. RB/S Pink Noise (1:00)
7. CB Pink Noise (1:00)
8. LB/S Pink Noise (1:00)
9. LF Pink Noise (1:00)
10. 100Hz Test Tone for CF
11. 100Hz Test Tone for RF
12. 100Hz Test Tone for RB/S
13. 100Hz Test Tone for CB
14. 100Hz Test Tone for LB/S
15. 100Hz Test Tone for LF
16. 1kHz Test Tone for CF
17. 1kHz Test Tone for RF
18. 1kHz Test Tone for RB/S
19. 1kHz Test Tone for CB
20. 1kHz Test Tone for LB/S
21. 1kHz Test Tone for LF
22. 5kHz Test Tone for CF
23. 5kHz Test Tone for RF
24. 5kHz Test Tone for RB/S
25. 5kHz Test Tone for CB
26. 5kHz Test Tone for LB/S
27. 5kHz Test Tone for LF
28. 50Hz Test Tone for CF
Front Panel Controls
• Power turned “On”
• Mode set to “PLII”
• Bass Blend turned “Off”
• Volume (see step #2)
• Shelf EQ turned “Off”
• Back & Side Low Pass turned “Off”
• Center Width adjustment “Centered”
• Dimension adjustment “Centered”
• Balance adjustment “Centered”
Rear Panel Controls
• FRONT HIGH PASS turned “Off”
• CENTER HIGH PASS turned “Off”
• BACK & SIDE HIGH PASS turned “Off”
• SUBWOOFER PHASE INVERT turned “Off”
• Subwoofer (RCA) output disconnected.
(You will reconnect the subwoofer after calibrating the
surround channels to ensure accurate measurements)
After you have completed the setup of your FAP V1 and your audio system is ready for speaker calibration, please insert the test
disc in your CD/DVD player.
Calibration:
To Properly calibrate your system ensure the following settings and selections have been made:
