Specifications
3300
Model FAP V1
Input Impedance 200kΩ (ohms)
Output Impedance (Main RCA) 750Ω (ohms)
Rated Output 2.0V rms
Maximum Output 15.0V rms (1% THD+N, 20-20kHz, 100k Ohm Load, Stereo Bypass
Shelf EQ. (Low Pass Filter) -3dB@5kHz
Front High Pass -3dB@80Hz
Center High Pass -3dB@80Hz
Back & Side High Pass -3dB@80Hz
Back & Side Low Pass -3dB@8kHz
Channel Gain Trim Control Range -6.5dB to +7.5dB, Volume @ Maximum
Nominal Voltage Gain 6dB, Volume @ Maximum
Output Polarity Inverting
Tubes (9) 6N1P Dual Triodes
(1) 5AR4 Dual Diode Rectifier
Supply Voltages 100V AC – 50Hz, 120V AC – 60Hz, 230V AC – 50Hz, 240V AC – 50Hz Technician Selectable
Power Consumption 180W (Watts)
Fuse Rating 100-120V AC Operation: 2.0Amp, 250V slow-blow 5x20mm (T2A 250V)
230-240V AC Operation: 1.0Amp, 250V slow-blow 5x20mm (T1A 250V)
Dimensions Width 21 inches (533.4mm)
Height 10.5 inches (266.7mm) includes feet
Depth 16 inches (406.4mm) Allow 2 inches (51mm) behind unit for connections
Weight 45 lbs. (20.4kg)
STEREO BYPASS
Frequency Response Left & Right: -3dB@6Hz and 70kHz, 100k Ohm Load
Subwoofer: -3dB@6Hz and 80Hz, 100k Ohm Load
THD+N Left & Right: <0.03%@1kHz, 1V rms Input, 100k Ohm Load, Volume @ Maximum
<0.2%@20-20kHz, 1V rms Input, 100k Ohm Load, Volume @ Maximum
Subwoofer: <0.08%@20-80Hz, 1V rms Input, 100k Ohm Load, Volume @ Maximum
Signal to Noise Ratio Left & Right: -95dBV A-Weighted, Volume @ Maximum, Input=1V rms then shorted
Subwoofer: -98dBV A-Weighted, Volume @ Maximum, Input=1V rms then shorted
Crosstalk Less than -60dB@1kHz
PL II
Frequency Response Surround Channels: +0dB, -3dB 20 to 20kHz, 100k Ohm Load
Subwoofer: -3dB@6Hz and 80Hz, 100k Ohm Load
THD+N Surround Channels: <0.3%@20-20kHz, 1V rms Input, 100k Ohm Load, Volume @ Maximum
Subwoofer: <0.07%@20-100Hz, 1V rms Input, 100k Ohm Load, Volume @ Maximum
7.1 BYPASS
Frequency Response Surround Channels: -3dB@6Hz and 70kHz, 100k Ohm Load
Subwoofer: -3dB@6Hz and 5kHz, 100k Ohm Load
THD+N Surround Channels: <0.3%@20-20kHz, 1V rms Input, 100k Ohm Load, Volume @ Maximum
Subwoofer: <0.02%@20-5kHz, 1V rms Input, 100k Ohm Load, Volume @ Maximum
Signal to Noise Ratio Surround Channels: -92dBV A-Weighted, Volume @ Maximum, Input=1V rms then shorted
Subwoofer: -98dBV A-Weighted, Volume @ Maximum, Input=1V rms then shorted
Specifications subject to change without notice
