DAD
Delay before door open alarm
warning
CSD
‘Relay 1’ stop delay after door
open
‘0’ … ‘900’ - time in seconds (‘-1’ = ‘Relay’ does not de-energise / ‘0’ = instantaneous / ‘1’-
’900’ = de-energises after prescribed time elapses)
DOT
Door stop overide If the door switch remains open for longer than ‘DOT’ minutes, the operating functionaity
returns to normal thermostatic control, howver the alarm will remain. When ‘DOT’ = ‘0’,
this function is disabled
DI1
‘DI1’ digital input ‘NON’ - Digital Input 1 not active
‘DOR’ - door input
‘ALR’ - when the input is activated (set by ‘D1A’) alarm ‘Alr’ alarm is generated, the
compressor is stopped and the defrosts are suspended
‘ECO’ - Do not use
‘RDS’ - Do not use
D1A
‘DI1’ activation ‘OPN’ - on open
‘CLS’ - on close
LCM
Light control mode ‘NON’ - light output not controlled
MAN’ - light output controlled through display operating button (when ‘SR1’, ‘SR2’ or ‘RL2’
= ‘LGT’ )
‘ECO’ - Do not use
‘DI1’ - Do not use
‘NI1’ - Do not use
‘DI2’ - Do not use
‘NI2’ - Do not use
SR1
SSR1 output operation ‘NON’ - Relay output disabled (always O/Open)
‘LGT’ - Output enabled for light control
‘0-1’ - Relay contacts follow the on/standby state of controller
R1’ - Do not use
‘R1F’ - Do not use
‘-R1’ - Do not use
‘FAN’ - Output enabled for evaporator fan switching
‘-FAN’ Do not use
‘DEF’ - Output enabled for defrost switching
‘-DEF’ - Do not use
‘ALO’ - Contacts open when an alarm condition occurs
‘ALC’ - Contacts make when an alarm condition occurs
‘ACP’ - Do not use
‘AFH’ - Do not use
SR2 SSR2 output operation Same operations and selection as ‘SR1’
RL2
RL2 output operation - same
operations and selection as
‘SR1’
Same operations and selection as ‘SR1’
ACN Do not adjust
ACF Do not adjust
AHS Do not adjust
AHU Do not adjust
AFT Do not adjust
PMD Do not adjust
MSV Do not adjust
2CD Do not adjust
SB Stand-by button enabling
BOS
Button Operation Sounder YES’ provides positive feedback (i.e. ‘beep’) every time a display button is pressed, ‘NO’
sounder is silenced during display button operation
RHC Do not adjust
OSA Probe TAir (T1) oset
TE
Probe TEvaporator (T2)
enabling
OSE Probe TEvaporator (T2) oset
T3A
DI2 / TAuxiliary Probe Enabling
and Operation
‘NON’ - DI2 / Auxiliary probe not tted
‘DSP’ - Auxiliary Probe - general purpose temperature measurement (i.e. stored product
temperature)
‘CND’ - Condenser probe - if measure temperature exceeds value of ‘AHT’ controller will
react as dened by ‘AHM’
‘2EU’ Do not use
‘DOR’ - Digital Input 2 used for door switch operation
‘ALR’ - Do not use
‘ECO’ - Do not use
‘RDS’ - Do not use
