4
D-108
1. SPECIFICATIONS
INPUT & OUTPUT
INPUT (1 ~ 8)
Connector RCA pin jack (x 8)
Input Level -10 dBV
Input Impedance 10 kΩ or more
OUTPUT (1 ~ 8)
Connector RCA pin jack (x 8)
Output Level -10 dBV
Load Impedance 10 kΩ or more
DATA IN / OUT
Connector Square shape optical
Format IEC consumer optical standard IEC 958 Part 3
ALESIS Proprietary Multi Channel Optical Digital Interface
MIDI IN / OUT / THRU
Connector DIN 5-pin
Format Comply to MIDI standard
PUNCH IN / OUT
Connector Ø6 mm phone jack (CMOS level)
SCSI
Connector D-SUB 25-pin
Protocol SCSI-2, unbalanced transfer method
Transfer Type Asynchronous
Number of Units Connected 2
RECORD & PLAYBACK
Recording Medium Internal 3.5” E-IDE hard disk drive (optional)
External fixed / removable SCSI-2 hard disk drive
Standard SCSI-2 or better
Sampling Frequency 44.1 kHz, 48kHz (Switchable by SETUP mode)
Quantization 16-bit linear
Emphasis Not available
Recording Time (mono track min.) About 18 min. / 100 MB at maximum (at Fs: 44.1 kHz)
Recording time will be limited up to 24 hours.
Number of Tracks 24 tracks (8 + 16 additional tracks)
Number of recording tracks at a time 8
Number of playback tracks at a time 8
Recording Format FDMS-3
Pitch Control ± 6.0 %
Crossfade 10 msec
OPERATION
Shuttle Speed 8 steps (7 steps for FWD direction)
CUE ON ± 1 ~ 8 times (FWD: ± 1 ~ 7 times)
CUE OFF ± 1 ~ 64 times
FFWD / REW Speed
CUE ON ± 3 times
CUE OFF ± 32 times
D-108
