D-108
5
OPERATION (continued)
Digital Scrubbing (JOG) 0 ~ 1 times (Envelope can be displayed when selecting only
one track.)
Locate Memory 6 (7 including [LOCATE] key temporary memory) + 99
LEVEL INDICATION
Type FL Bargraph
Number of Indicated Levels 11 dots (-∞, -42, -30, -24, -18, -12, -9, -6, -3, 0, OVER)
Reference Level (-10 dBV) Indication -12 dB
DIMENSIONS 148 (H) x 482 (W) x 381 (D) mm
WEIGHT 8 kg
POWER REQUIREMENT
JPN 100 V AC
USA / CND 120 V AC
EUR / UK 230 V AC
POWER CONSUMPTION Approx. 33 W
STANDARD ENVIRONMENT
Standard Temperature 20 ± 2 ºC
Standard Humidity 65 ± 5 %
ENVIRONMENT CONDITION (W/O HD)
Characteristics Guaranteed
Temperature + 5 ~ + 40 ºC
Humidity 30 ~ 70 %
AC voltage deviation ± 5 % or less
Operation Guaranteed
Temperature - 5 ~ + 45 ºC
Humidity 85 % or less
AC voltage deviation ± 10 % or less
CHARACTERISTICS
Overall Frequency Response 20 ~ 20 kHz +1, -2 dB
Signal to Noise Ratio 88 dB or more (between ADC and DAC)
Dynamic Range 88 dB or more (between ADC and DAC)
T.H.D. 0.008 % or less (at 1 kHz, -1 dBV)
Channel Separation 80 dB or more (at 1 kHz)
Phase Difference between Channels 20 º or less
8345
INPUT & OUTPUT
TIME CODE INPUT
Format SMPTE
Connector XLR-3-31 type (Pin 1: GND, Pin 2: HOT, Pin 3: COLD)
Standard Input Level 2 V p-p
Minimum Input Level 0.25 V p-p
Input Impedance 20 kΩ or more
To Next Page
