Fostex D-108 Service Manual

6
D-108
TIME CODE OUTPUT
Format SMPTE
Connector XLR-3-32 type (Pin 1: GND, Pin 2: HOT, Pin 3: COLD)
Standard Output Level 2 V p-p
Minimum Output Level 0.25 V p-p
Load Impedance 20 kΩ or more
VIDEO INPUT
Format Composite (Applied video signal must comply to PAL or
NTSC standard and be interlace type)
Connector BNC
Frame Pulse 24, 25, 29.97, 30 Hz (± 1000 ppm)
Field Pulse 48, 50, 59.94, 60 Hz (± 1000 ppm)
Standard Input Level 1 V p-p
Input Impedance 75 Ω (ON / OFF by terminator SW)
VIDEO THRU
Connector BNC
Output Level Direct output of signal fed to Video Input connector
WORD INPUT
Connector BNC
Frequency 44.1, 48 kHz
Standard Input Level TTL level
Input Impedance 75 Ω (ON / OFF by terminator SW)
WORD OUTPUT
Connector BNC
Standard Output Level TTL level
Load Impedance 75 Ω (ON / OFF by terminator SW)
DIMENSIONS 215 (W) x 80 (D) mm
POWER SUPPLY Supplied from D-108
Digital DC + 5 V
Analog DC + 19 V / - 15 V
5040
INPUT (1 ~ 8)
Connector D-SUB 25-pin
Standard Input Level + 4 dBu
Input Impedance 10 kΩ or more
OUTPUT (1 ~ 8)
Connector D-SUB 25-pin
Output Level + 4 dBu
Load Impedance 600 Ω or more
DIMENSIONS 270 (W) x 70 (D) mm
POWER SUPPLY DC + 15 V (Supplied from D-160)
Specifications and appearance are subject to change without notice for product improvement.
