24
FD-4
7. EXPLODED VIEW, PCB ASSEMBLY AND PARTS LIST
FD-4 OVERALL EXPLODED VIEW & PARTS LIST
Ref. No. Part No. Description
1 8212 6100 00 Window, LCD, FD-4
2 8212 6090 00 Panel, top, FD-4
3 8221 2290 00 Panel, bottom, FD-4
4 8274 1240 00 PCB assy, XLR, FD-4
5 8216 6641 00 Shield, mixer, FD-4
6 8226 2370 00 Button assy, control, FD-4
7 8274 1220 00 PCB assy, Mixer A, FD-4
8 82262230 01 Knob, volume, C
9 8274 1360 00 PCB assy, Display, FD-4
10 82741370 00 PCB assy, Main, FD-4
11 82741380 00 PCB assy, Power, FD-4
12 8204 0820 00 Plate, mounting, B
13 82212270 00 Bracket, jack, FD-4
14 82741230 00 PCB assy, Jack, FD-4
15 8226 2380 00 Knob, jog, FD-4
16 8216 6670 00 Sheet, jog, FD-4
17 8226 1601 03 Knob, slide, N4.5
18 8226 2390 01 Knob, fader, N4.5
19 8207 0005 00 Cord, holder
20 8207 0120 00 Foot, FF-822
21 8276 8351 00 Cord, power, CSA, non
integral, USA/CND
82760030 00 Cord, power, JPN
82760060 00 Cord, power, EUR
82768790 00 Cord, power, BS, 2C, PHE-8,
UK
22 8207 0084 00 Bushing, 2271 (Except CND)
82070084 01 Bushing, 3P31, CND
23 82534620 01 SW, P, Power, SDDJF1-A-2
24 8216 6650 00 Sheet, isolation, power, FD-4
25 82166361 00 Cushion, battery, PD-4/FD-4
26 8242 2340 13 Filter, EMI, ferrite, core,
HF70RH16x28x10
27 8276 9140 06 Tube, UL, black, L60
28 8276 8720 14 Tube, UL, clear, 16, L140
29 82763750 09 Cable assy, earth lug, D3,
L90
30 8207 0117 01 Cord holder, CS-1
31 82773530 15 Cable assy, earth lug, D3-D3,
#20, L150
Ref. No. Part No. Description
32 82773530 20 Cable assy, earth lug, D3-D3,
#20, L200
33 82741390 00 PCB assy, AC In, FD-4
34 8239 0007 08 Fuse, 20, TDLY, 0.8A, 250V
35 8216 6361 01 Cushion, button, FD-4
!
!
!
!
To Next Page
