Fostex FD-4 - Maintenance;Specifications

96
MIDI Implementation Chart/MMC List/Maintenance/Specifications
Maintenance
Specifications
Cleaning the exterior
* For normal cleaning, use a soft dry cloth
For stubborn dirt, moisten a cloth in diluted detergent, wring it out firmly, and wipe the dirt off.
Then polish with a dry cloth.
Never use solvents such as alcohol, thinner or benzene, since these will damage the printing and finish of the exterior.
* Mixer section
<INPUT 1, 2>
Connector : 6mm Phone jack (x 2)
Input Impedance : 20k ohm or higher
Reference Input Level : -10dBV
<INPUT 3, 4>
Connector : 6mm Phone jack (x 2)
: XLR-3-31 type (x 2)
Input Impedance : 20k ohm or higher
Reference Input Level : L: -50dBV, M: -30dBV,
L: -10dBV
<INSERT 3, 4>
Connector : 6mm Phone jack (x 2)
Load Impedance : 10k ohm or higher
Reference Output Level : -10dBV
Input Impedance : 10k ohm or higher
Reference Input Level : -10dBV
<AUX SEND 1, 2>
Connector : 6mm Phone jack (x 2)
Load Impedance : 10k ohm or higher
Reference Output Level : -10dBV
<AUX RTN 1, 2>
Connector : 6mm Phone jack (x 4)
Input Impedance : 8k ohm or higher
Reference Input Level : -20dBV
<STEREO OUT L, R>
Connector : RCA pin jack (x 2)
Load Impedance : 10k ohm or higher
Reference Output Level : -10dBV
<MONITOR OUT L, R>
Connector : 6mm Phone jack (x 2)
Load Impedance : 10k ohm or higher
Reference Output Level : -10dBV
<PHONES OUT>
Connector : 6mm Stereo Phone jack
Load Impedance : 16 ohm or higher
<RECORDER IN L, R>
Connector : RCA Pin jack (x 2)
Input Impedance : 20k ohm or higher
Reference Input Level : -10dBV
<DATA IN/OUT>
Connector : Optical (x 2)
Format : IEC 958 Part 3 (S/P DIF)
<MIDI IN/OUT>
Connector : DIN 5 pin
Format : MIDI
<PUNCH IN/OUT>
Connector : 6mm Phone jack (x 1)
(An optional FOOT SW Model 8051 can be connected.)
<Equalizer>
HI : 12kHz +/-15dB (Shelving Type)
MID : 200Hz ~ 5kHz +/- 15dB (Parametric Type)
LO : 80Hz +/- 15dB (Shelving Type)
<Frequency Response> : 20Hz ~ 20kHz
* Recorder section
<Recording/Reproducing>
Recording Medium : External SCSI device
(SCSI-2, asymmetrical transfer)
: Internal 2.5 inch hard disk (E-
IDE type)
: Connectable SCSI device: One
<Recording Format> : FDMS-3*
(* Fostex Disk Management
System-3)
<Recording Mode>
Normal Mode : 4 Real track + 2 Additional
track (Sampling Rate: 32kHz/
DAC*)
(*) Digital Audio Acoustic
Coding)
