3
English
Introduction
Features of PC100USB-HR2
• Volume controller which supports USB input.
• Can remotely control the volume of headphones and speaker systems.
• Compact and robust.
• Can be used as is - no additional cables are required.
• Can be used as an OS standard driver for Windows and Mac OS X.
• Supports maximum 96 kHz/24 bit (PCM) input using a playback application compatible with high
resolution sound or similar.
Accessories
Supplied accessories are listed below. Confirm that these accessories are present after purchase.
• USB cable (AB type/1 m) × 1
• RCA pin cable (1.5 m) × 2
• Owner’s manual (this manual) × 1
Computer requirements
Computers that will be connected to the unit must have the following specifications.
• OS: Windows 7 or above, Mac OS X V10.6 or above
• USB: USB2.0 compatible
Specifications
[OUTPUT] (L/R)
terminals
Connector RCA pin jack
Adapted load impedance 10 kΩ or more
Standard output level +6 dBV (0 dBFS)
[PHONES] terminal Connector Φ3.5 stereo mini jack
Adapted load impedance 32 Ω or more
Rated output 30 mW + 30 mW
(32 Ω load, THD 0.5% or less)
[USB] terminal Connector USB type B connector
Supported sampling frequencies (kHz) 32, 44.1, 48, 88.2, 96
Quantization bit rate 16/24 bit
Power USB bus power (5 V, 500 mA)
Power consumption 2.5 W maximum
Weight Approx. 210 g (not including cables)
External dimensions 66 mm (Width) × 44 mm (Height) × 70 mm (Depth)
