FoxAlien 3018-SE - Back Acrylic Case Panel Installation

-12-
Part
-9 Case Assembly- Back Panel
Required
Parts
No. Name QTY Picture
(7)
Back Acrylic Sheet
1
(17)
M5*10 Modified Truss Screw
2
Step 1:
First, wire the fan to the mainboard; and then use M5*10 Modified Truss Screws to fix the back
acrylic sheet to the transparent pads.
I. Hardware Assembly
