FoxAlien 3018-SE - Left Acrylic Case Panel Installation

-7-
Part
-4 Case Assembly-Left Panel
Required Parts
No. Name QTY Picture
(5)
Left Acrylic Sheet
1
(17)
M5*10 Modified Truss Screw
2
Step 1:
Use M5*10 Modified Truss Screws to fix the left acrylic sheet to the transparent pads which
are pre
-installed on the base.
I. Hardware Assembly
