FoxAlien 3018-SE - Corner Connector Installation

-14-
Part
-10 Corner Connector Assembly
Required
Parts
No. Name QTY Picture
(11)
Corner Connector
2
(17)
M5*10 Modified Truss Screw
4
Step 1:
Put the corner connector inside the case, fix it with M5*10 Modified Truss Screw from outside.
I. Hardware Assembly
