-15-
Part
-11 Case Assembly-Front Panel
Required
Parts
No. Name QTY Picture
(9)
Front Acrylic Sheet &
Door
Handle
1
(16)
M4*8 Flat Head Screw
4
(10)
Corner Connector
1
(17)
M5*10 Modified Truss Screw
3
Step 1: Use M5*10 Modified Truss Screws to fix the corner connector to right acrylic sheet.
I. Hardware Assembly
