FoxAlien 3018-SE - Control Board Mounting and Wiring

-3-
Part
-2 Control Board Assembly
Required
Parts
No. Name QTY Picture
(4)
Control board
1
Step 1: Assemble the control board to the back of the machine, right next to the side panel. First
loosen the T-nuts, insert them to the aluminum profile, and then tighten the screws.
I. Hardware Assembly
