3.2 Panel Descriptions
On the Front Panel of the 7320 Transmitter and Receiver unit are two LEDs. The
following tables describe the LEDs.
Table 1 - 7320 Transmitter LEDs
LED Name LED Function
Laser
Indicates if the optical output power control is functioning
RF
Indicates if the RF signal is above the minimal level
Table 2 - 7320 Receiver LEDs
LED Name LED Function
Opt.
Indicates if the optical reception power is within limits
RF
Indicates if the RF signal is above the minimal level
