Foxconn D42S User Manual

4
1
1-2 Layout
Note : The above motherboard layout is for reference only, please refer to the physical
motherboard for detail.
1. TPM Connector
2. Front Audio Connector
3. Front USB Connectors
4. PCI Slot
5. SPDIF_OUT Connector
6. Clear CMOS Jumper
7. Chipset: Intel
®
NM10 Express
8. Chassis Intrusion Alarm Header
9. Front Panel Connector
10. SATA Connectors
11. 24-pin ATX Power Connector
12. DDR2 DIMM Slots
13. System Fan Header
14. CPU Fan Header
15. 4-pin ATX 12V Power Connector
16. COM2 Connector
17. IR/CIR Connector
11
16
12
13
14
17
15
13
2
6
7
5
4
9
8
10

Foxconn D42S Specifications

General

Brand	Foxconn
Model	D42S
Category	Motherboard
Language	English
