30
3
When enable, the suspend power of the NM10 Express chipset will be cut off in S5 suspend
mode; when disable, the suspend power is always on.
This item is used to assign the I/O address and interrupt request (IRQ) for the onboard serial
port 1.
This item is used to assign the I/O address and interrupt request (IRQ) for the serial port 2.
This item is used to assign the I/O address for the onboard parallel port.
This item is used to set parallel port mode.
This item is used to assign interrupt request (IRQ) for the onboard parallel port.
This item is used to assign the I/O address for onboard infrared chip.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
SuperIO Conguration
Congure ITE8721 Super IO Chipset Help Item
EUP Function [Enabled]
Serial Port1 Address [3F8/IRQ4]
Serial Port2 Address [2F8/IRQ3] Disabled[2F8/IRQ3] Disabled Disabled
Serial Port2 ModeSerial Port2 Mode [Normal] Enabled
Parallel Port Address [378]Parallel Port Address [378] [378]
Parallel Port Mode [Normal]
Parallel Port IRQ [IRQ7]
OnBoard CIR Port [Disabled]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[Enabled]
