PC Health Status
This option is used to set the warning temperature for the system. When the temperature of
CPU is higher than the set value, the motherboard will send out warning information.
This item is used to set the system temperature upper limit. When the temperature exceeds
the set value, the system will shut down automatically.
This item is used to enable or disable case open warning function.
The CPU/System temperature are automatically detected and displayed by the system.
The CPU/System fan speed are automatically detected and displayed by the system.
The current voltages are automatically detected and displayed by the system.
This option is used to enable or disable smart fan function.
The following 4 settings are valid only when Smart Fan Control is set to [Enabled].
OFF Temperature
It allows you set a temperature value from which smart fan stops its operation.
PWM Start TemperatureStart TemperatureTemperature
It allows you set a temperature value from which smart fan starts its operation.
Start PWM Value
It allows you to set an initial PWM value to drive the fan when the temperature reaches Start
value and smart fan begins its operation. The higher PWM value can achieve the faster fan
speed.
Slope PWM Value
The slope controls the PWM value being stepped up or down versus temperature changes.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
PC Health Status
�arning Temperature [Disabled] Help Item
ShutDown Temperature [Disabled]
Case Open �arning [Disabled]
CPU Temperature :38
o
C/100
o
F
System Temperature :22
o
C/71
o
F
CPU Fan Speed :3590 RPM
System Fan Speed :N/A
CPU Core :1.136 V
DRAM Voltage :1.552 V
+3.30V :3.376 V
+5.00V :5.107 V
+12.0V :10.176V
CPU Smart Fan Control [Disabled]
System Smart Fan Control [Disabled]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[Disabled]
Options
Disabled
50
o
C/122
o
F
55
o
C/131
o
F
60
o
C/140
o
F
65
o
C/149
o
F
70
o
C/158
o
F
75
o
C/167
o
F
80
o
C/176
o
F
85
o
C/185
o
F
90
o
C/194
o
F
