1-1 Product Specications
CPU Support LGA775 socket Intel
®
CPU:
Core
TM
2 Quad / Core
TM
2 Duo / Pentium
®
Dual-Core /
Celeron
®
Dual-Core / Conroe-L processors
Supports 45nm processor
Front Side Bus 1333/1066/800MHz FSB
Chipset North Bridge: Intel
®
G41
South Bridge: Intel
®
ICH7
Memory 2 x 240-pin DDR3 DIMM sockets
Support up to 8GB of system memory
Dual channel DDR3 1066/800MHz architecture
Audio Realtek 6-channel audio chip (G41MXE)
Realtek 8-channel audio chip (G41MXE-K)
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF out
Support Jack-Sensing function
LAN Realtek 10/100/1000Mb/s LAN chip
Expansion Slots 1 x PCI Express x16 slot
1 x PCI Express x1 slot
2 x PCI slots
Onboard Serial ATA 4 x SATA connectors
300MB/s data transfer rate
Support hot plug and NCQ (Native Command Queuing )
USB Support hot plug
Support up to 8 x USB 2.0 ports (4 rear panel ports, 2 onboard USB
headers supporting 4 extra ports)
Supports USB 2.0 protocol up to 480Mb/s
Internal Connectors 1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
1 x Floppy connector
1 x IDE connector
4 x SATA connectors
2 x USB 2.0 connectors (supporting 4 x USB devices)
1 x CPU fan header (4-pin)
1 x System fan header (4-pin)
1 x Front Panel connector
1 x CD_IN connector
1 x Front Audio connector
1 x IR connector
1 x S/PDIF_OUT connector
1 x Speaker connector
1 x TPM connector
1 x COM2 connector

Foxconn G41MXE Series Specifications

General

Form Factor	Micro ATX
CPU Socket	LGA 775
Maximum Memory	8 GB
Storage Interface	4 x SATA 3Gb/s, 1 x IDE
Integrated Graphics	Intel GMA X4500
Audio	Realtek ALC662 6-Channel HD Audio
USB Ports	8 x USB 2.0 (4 on back panel, 4 via headers)
Video Outputs	1 x VGA
Chipset	Intel G41
Memory Slots	2 x DIMM
Expansion Slots	1 x PCIe x16, 2 x PCI
LAN	Realtek RTL8103EL, 10/100 Mbps
