► Serial Port1 Address
This item is used to assign the I/O address and interrupt request(IRQ) for the onboard serial
port1.
► Serial Port1 Mode
This item is used to set the mode for the onboard serial port1. The available settings are:
[Normal]: RS232 Mode.
[IrDA]: An IrDA device for maximum 115200bit/s.
[ASK IR]: A faster IrDA for 1152000bit/s.
► Parallel Port Address
This item is used to assign the I/O address and interrupt request(IRQ) for the onboard parallel
port.
► Parallel Port Mode
This item is used to select the operation modes for the onboard parallel (or Printer) port. They
are [Normal] (default), [EPP], [ECP] and [ECP+EPP].
► Parallel Port IRQ
This item is used to assign interrupt request(IRQ) for the onboard parallel port.
► OnBoard CIR Port
This item enables you to determine the transfer mode of the onboard infrared chip.
USB Conguration
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
USB Conguration
USB Conguration Help Item
Module Version - 2.24.5-13.4
USB Devices Enabled :
2 Hubs
Legacy USB Support
USB 2.0 Controller Mode [HiSpeed]
BIOS EHCI Hand-Off [Enabled]
Legacy USB1.1 HC Support [Enabled]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[Enabled]
Enables support for
legacy USB. AUTO
option disables
legacy support if
no USB devices are
connected.
► Legacy USB Support
This item is used to enable the support for USB devices on legacy OS. If you have a USB
keyboard or mouse, set to auto or enabled.
► USB 2.0 Controller Mode
This item is used to set the transmission rate mode of USB 2.0. The available settings are :
[HiSpeed] in 480Mbps; [Full Speed] in 12Mbps.
► BIOS EHCI Hand-Off
Windows XP supports a number of features in the Enhanced Host Controller Interface (EHCI)
specication, but there are a few features that are not implemented. Microsoft said preliminary
support for EHCI BIOS handoff will be available in Windows XP SP2.

Foxconn H55MXV LE Specifications

General

Form Factor	Micro ATX
CPU Socket	LGA 1156
Memory Type	DDR3
Maximum Memory	8 GB
PCIe 2.0 x1 Slots	1
USB Ports (Rear)	4
Chipset	Intel H55
Memory Slots	2
Expansion Slots	1 x PCIe x1
Audio	Realtek ALC662
LAN	Realtek RTL8111DL Gigabit Ethernet
Video Outputs	VGA
USB Ports	8 (4 rear, 4 via headers)
VGA Port	Yes
