BIOS SETUP
33
Super IO Conguration
Super IO Configuration
Super IO Chip IT8728
▶ Serial Port 0 Configuration
▶ Serial Port 1 Configuration
▶ Parallel Port Configuration
▶ CIR Controller Configuration
Set Parameters of
Serial Port 1 (COMB)
→ ←: Select Screen
↑ ↓/Click: Select Item
Enter/Dbl Click: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Version 2.14.1219. Copyright (C) 2012 American Megatrends, Inc.
Main Advanced Boot Power Health SecurityF-center Save&Exit
Serial Port 0/1 Conguration
► Serial Port
This item is used to enable or disable the serial port (COM).
► Device Settings
This item shows the resource assigned to the serial port.
► Change Settings
This item is used to select an optimal settings for Super IO device.
Parallel Port Conguration
► Parallel Port
This item is used to enable or disable the parallel port (LPT/LPTE).
► Device Settings
This item shows the resource assigned to the serial port.
► Change Settings
This item is used to select an optimal settings for Super IO device.
► Device Mode
This item is used to change the printer port mode.
CIR Controller Configuration
► CIR Controller
This item is used to enable or disable the onboard CIR controller.
► Device Settings
This item shows the resource assigned to the CIR controller.
► Change Settings
This item is used to select an optimal settings for Super IO device.
