PRODUCT INTRODUCTION

Internal

Connectors

1 x LPT header

1xCOM2header

1 x Speaker header (

Buzzer Reserved

)

1 x TPM header

Back Panel

Connectors

1xPS/2Keyboardport

1xPS/2Mouseport

1xRJ45LANport

1 x COM1 port

1 x DVI-D port (H87MX-D/H81MX-D/H81MX-V)

1 x VGA port

1 x HDMI port (H87MX/H81MX)

2xUSB2.0ports

2xUSB3.0ports

3 x Audio ports

Hardware Monitor System voltage detection

CPU/System temperature detection

CPU/System fan speed detection

CPU Overheating warning

CPU/System fan speed control

Green Function

SupportACPI(AdvancedCongurationandPowerInterface)

Support S3(suspendtoRAM),S4(suspendtodisk)

SupportDeepS4,S5Function

Support EuP function

Bundled Software FOX ONE

FOX LiveUpdate

FOX LOGO

FOX DMI

Smart Charger

Operating System Support for Microsoft

Windows

8/7

Form Factor MicroATXFormFactor,9.6inchesx7.0inches(24.4cmx17.8cm)

Foxconn H81MX Series User Manual
