Foxconn H81MX Series User Manual

PRODUCT INTRODUCTION
4
1-2 Layout
1. Speaker Header
2.PCIExpressX16Slot
3. PCI Express X1 Slot
4.INTRHeader
5.PCISlot
6. Front Audio Header
7. LPT Header
8.COM2Header
9. TPM Header
10.FrontUSB2.0Headers
11. SATA Connectors
12.FrontPanelHeader
13. Chipset: Intel® H87/H81
14.ME Header
15.ClearCMOSHeader
16.24-pinATXPowerConnector
17. DDR3 DIMM Slot
18. SYS_FAN1 Header
19. CPU_FAN1 Header
20.LGA1150CPUSocket
21.4-pinATX12VPowerConnector
The above motherboard layout is for reference only, please refer to the physical
motherboard for detail.
18
19
20
21
13 14 15
17
16
7
8
9
11
12
10
123456

Foxconn H81MX Series Specifications

General

Brand	Foxconn
Model	H81MX Series
Category	Motherboard
Language	English
