Foxconn H81MX Series User Manual

Health
►CaseOpenWarning
This item is used to enable or disable case open warning function.
►CPUWarningTemperature
This option is used to set the warning temperature for the system. When the temperature of
CPU is higher than the set value, the motherboard will send out warning information.
►CPUShutdownTemperature
This item is used to set the system temperature upper limit. When the temperature exceed-
sthe set value, the system will shut down automatically.This function works only when your
operating system is supporting ACPI.
►CPUSmartFanControl
This option is used to enable or disable CPU smart fan function. Default value is [Disabled].
►SystemSmartFanControl
This option is used to enable or disable system smart fan function. Default value
Case Open Warning [Disabled]
CPU Temperature : +39 ˚C
System Temperature : +35 ˚C
CPU Fan Speed : 3026 RPM
System Fan Speed : N/A
CPU Vcore : +1.200 V
DRAM Voltage : +1.608 V
+12V SYS : +21.300 V
+5V SYS : +5.097 V
VBAT : +3.328 V
CPU Warning Temperature [Disabled]
CPU Shutdowm Temperature [Disabled]
CPU Smart Fan Control [Disabled]
System Smart Fan Control [Disabled]
Enabled Case Opening Warn-
ing and open chassis,
Instruction Alarm will
appear. If don’t enter
bios setup and disabled
Case Opening Warning one
time, Instruction Alarm
don’t clear, it will
appear all the time.
→ ←: Select Screen
↑ ↓/Click: Select Item
Enter/Dbl Click: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Version 2.15.1236. Copyright (C) 2013 American Megatrends, Inc.
Main Advanced Boot Power Health SecurityF-center Save&Exit
BIOS SETUP
