Foxconn H81MX Series User Manual

Performance Tuning
▶ CPU Configuration
▶ North Bridge Configuration
CPU Configuration
→ ←: Select Screen
↑ ↓/Click: Select Item
Enter/Dbl Click: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Version 2.15.1236. Copyright (C) 2013 American Megatrends, Inc.
Main Advanced Boot Power Health SecurityF-center Save&Exit
CPUConguration
►EIST
You can select the EIST (Processor Power Management, PPM) through this item.
Enhanced Intel SpeedStep® technology (EIST) allows the system to dynamically
adjust processor voltage and core frequency, which can result in decreased average
power consumption and decreased average heat production. There are some
system requirements must be met, including CPU, chipset, motherboard, BIOS and
operation system. Please refer to Intel Website for more information.
CAUTIO
N
►TurboMode
Turbomodeallowsprocessorcorestorunfasterthanitsmarkedfrequencyinspecic
condition.
NorthBridgeConguration
►PerformanceMemoryProles
ThisitemisusedtoselectPerformancememoryprole.
Options:[Automatic],[Manual],[XMPProle1],[XMPProle2].
[Automatic]-Congurationdatabaseofusingperformancememoryprole.
[Manual]-Congurationdatabaseofusingperformancememoryprole.Thenextsubmenu
will appear when select this item.
[XMPProle1]-CongurationdatabaseofusingXMPtimingprole1.
[XMPProle2]-CongurationdatabaseofusingXMPtimingprole1.
The following items appear only when the option is set to “Manual”.
►MemoryClockMultiplier
This item is used to set the memory clock multiplier.
►MemoryMultiplier
BIOS SETUP
27
