Foxconn H81MX Series User Manual

CD INSTRUCTION
56
5. Voltage Page - Voltage Control (Optional)
This page lets you set CPU voltage, memory voltage and North Bridge voltage manually. CPU
voltagecanbesteppedup/downbyaunitof12.5mV,whilememoryis0.05V/step,andNorth
Bridgeis0.04V/step.
6. Fan Page - Fan Control
This page lets you enable Smart Fan function or set the fan speed by manual.
WhenSmartFanisselected,youmustusea4-pinCPUcoolerinyoursystem.
Go to Voltage page
Select the option
you want to set
Adjust by manual
Reset the changes
Apply the changes
Go to Fan page
Set fan speed by
dragging the lever
Enable or disable
smart fan function
Apply the changes
