Foxconn H81MX Series User Manual

PRODUCT INTRODUCTION
2
(Continued on the next page)
1-1 Product Specications
CPU Support Intel
®
HaswellLGA1150Processors
Maxprocessorpowerupto95W
For the latest CPU information, please visit:
http://www.foxconnsupport.com/cpusupportlist.aspx
Chipset Intel
®
H87/H81
Memory 2x240-pinDDR3DIMMs
Support up to 16GB of system memory
Dual channel DDR3 1600/1333 MHz architecture
Expansion Slots 1 x PCI Express X16 slot
-SupportPCIExpressGen25GT/sdatarate
-Support PCI Express Gen3 8GT/s data rate
1 x PCI Express X1 slot
-SupportPCIExpressGen25GT/sdatarate
2xPCIslots
Storage Intel
®
H87 chipset
-4xSATA3.0connectors(6Gb/sdatatransferrate)
Intel
®
H81 chipset
-2xSATA2.0connectors(3Gb/sdatatransferrate)
-2xSATA3.0connectors(6Gb/sdatatransferrate)
LAN Realtek RTL8111F-CG LAN controller
Support 10/100/1000Mbps
Audio RealtekALC662-VD0-GR
-HighDenitionAudio
-2/4/5.1-channel
-Support Jack-Sensing function
USB Supportupto6xUSB2.0ports(2rearpanelports,2onboardUSB
headerssupporting4extraports)
SupportUSB2.0protocolupto480Mb/s
Supportupto2xUSB3.0ports(2rearpanelports)
SupportUSB3.0protocolupto5Gb/s
Internal
Connectors
1x24-pinATXpowerconnector
1x4-pinATX12Vpowerconnector
4xSATA3.0connector(H87MX/H87MX-D)
2xSATA3.0connector(H81MX/H81MX-D/H81MX-V)
2xSATA2.0connector(H81MX/H81MX-D/H81MX-V)
2xUSB2.0header(supporting4xUSBdevices)
1xCPUFAN1header(4-pin)
1xSystemFAN1header(4-pin)
1 x Front panel header
1 x Front audio header
1 x INTR header
1 x Clear CMOS header
1 x ME header
