Voltage Options
► CPU Voltage Margining Step
This item is used to set the CPU voltage margining offset. You can adjust CPU voltage by a
voltage step of 0.0125V * number each.
► Memory Voltage Control
This item is used to select a voltage for memory. Voltage ranges from 1.665V to 2.340V.
► 1.28X Memory Voltage Table
This item is used to raise the voltage ranged in the Memory Voltage Control setting, Higher
voltage options are provided. Voltage ranges from 2.131V to 2.995V.
► 1.13X Memory Voltage Table
This item is used to raise the voltage ranged in the Memory Voltage Control setting. Voltage
ranges from 1.894V to 2.662V.
► NB/PCIE Voltage Control
This item is used to set the Northern Bridge/PCI-Express voltage control.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Voltage Options
Voltage Options Help Item
Current CPU Voltage :1.272 V CPU Voltage Margining
Current Memory Voltage :1.728 V offset = 12.5mV x Step
Current GMCH Voltage :1.224 V
CPU Voltage Margining Step [0 ]
12.5mV x 0 = 0.0mV
Memory Voltage Control [Default]
1.28X Memory Voltage Table [Disabled]
1.13X Memory Voltage Table [Disabled]
NB Voltage Control [Default]
PCIE Voltage Control [Default]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F7:Previous Values F8:Fail-Safe Defaults F9:Optimized Defaults
