3. Select Hitachi hard disk as the one to be reset. Press <Enter>. A double
conrmation message pops out, press <Y> to conrm.
4. It goes back to Main menu with a "Failed" status of RAID0 volume.
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
1. Create RAID Volume 4. Recover Volume Options
2. Delete RAID Volume 5. Acceleration Options
3. Reset Disks to Non-RAID 6. Exit
RAID Volume :
ID Name Level Stripe Size Status Bootable
0 TryRAID0 RAID0(Stripe) 128KB 298.1GB
Normal Yes
0 Hitachi HDS72161 PVF904Z21G2JZM 149.0GB
Member Disk(0)
1
ST380811AS 5PS1TAGW 74.5GB Non-RAID Disk
2
SAMSUNG HD161HJ S0V3J9APA30524 149.0GB Member Disk(0)
3
ST380815AS 5RW1CA37 74.5GB Non-RAID Disk
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
Intel(R) Rapid Storage Technology - Option ROM - 9.5.0.1021
Copyright(C) 2003-09 Intel Corporation. All Rights Reserved.
[ DISK/VOLUME INFORMATION ]
[ MAIN MENU ]
Resetting RAID disk will remove its RAID structures
and revert it to a non-RAID disk.
WARNING: Resetting a disk causes all data on the disk to be lost.
( This does not apply to Recovery volumes)
Port Drive Model Serial # Size Status
►0 Hitachi HDS721616PLA PVF904Z21G2JZM 149.0GB Member Disk
2
SAMSUNG HD161HJ S0V3J9APA30524 149.0GB Member Disk
Select the disks that should be reset.
[↑↓]-Previous/Next [SPACE]-Selects [ENTER]-Selection Complete
0 Hitachi HDS721616PLA PVF904Z21G2JZM 149.0GB Member Disk
[ RESET RAID DATA ]
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
1. Create RAID Volume 4. Recover Volume Options
2. Delete RAID Volume 5. Acceleration Options
3. Reset Disks to Non-RAID 6. Exit
RAID Volume :
ID Name Level Stripe Size Status Bootable
0 TryRAID0 RAID0(Stripe) 128KB 298.1GB
Failed Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
0 Hitachi HDS72161 PVF904Z21G2JZM 149.0GB
Non-RAID Disk
1
ST380811AS 5PS1TAGW 74.5GB Non-RAID Disk
2
SAMSUNG HD161HJ S0V3J9APA30524 149.0GB Member Disk(0)
3
ST380815AS 5RW1CA37 74.5GB Non-RAID Disk
Intel(R) Rapid Storage Technology - Option ROM - 9.5.0.1021
Copyright(C) 2003-09 Intel Corporation. All Rights Reserved.
[ DISK/VOLUME INFORMATION ]
[ MAIN MENU ]
3. Reset Disks to Non-RAID
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
