Integrated Peripherals
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Integrated Peripherals
► IDE Conguration
[Press Enter] Help Item
► OnBoard Conguration
[Press Enter]
► SuperIO Conguration
[Press Enter] Congure the IDE
► USB Conguration
[Press Enter] Device(s).
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[Press Enter]
► IDE Configuration/OnBoard Configuration/SuperIO Configuration/USB Configuration
Press <Enter> to go to relative submenu.
IDE Conguration
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
IDE Conguration
Congure SATA as [IDE] Help Item
SATA#1 IDE Configuration [Enhanced]
SATA#2 IDE Conguration
[Enhanced]
IDE Detect Time Out
[35]
IDE
RAID
AHCI
Disabled
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[IDE]
Options
► Configure SATA as
This item is used to set the operation mode of your SATA ports 1, 2, 3, 4, 5, 6. Set to [IDE]
can congure the SATA ports to support IDE mode.
► SATA#1 IDE Configuration
SATA#1 are the SATA ports 1, 2, 3, 4 of the motherboard. This item allows you select the
mode of the SATA ports. Setting values are: [Compatible], [Enhanced].
► SATA#2 IDE Configuration
SATA#2 are the SATA ports 5,6 of the motherboard. This item allows you select the mode of
the SATA ports. Setting values are: [Disabled], [Enhanced].
