Advanced BIOS Features
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Advanced BIOS Features
Quiet Boot [Enabled Help Item
Bootup Num-Lock [On]
PCI Latency Timer [64]
Floppy Drive Seek [Disabled]
► Intel VT-d Conguration
[Press Enter]
► Trusted Computing [Press Enter]
► Boot Device Priority [Press Enter]
► Hard Disk Drives
[Press Enter]
► Removable Drives
[Press Enter]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[Enabled]
Disabled: Displays
normal POST messages.
Enabled: Displays OEM
Logo instead of POST
messages.
► Quiet Boot
This item is used to enable/disable the quiet boot.
[Disabled] : Displays the normal POST messages.
[Enabled] : Displays OEM customer logo instead of POST messages.
► Bootup Num-Lock
This item denes if the keyboard Num Lock key is active when your system is started. The
available settings are: On (default) and Off.
► PCI Latency Timer
This item is used to set the value in units of PCI clocks for PCI device latency timer register.
► Floppy Drive Seek
This item controls whether the BIOS will be checking for a oppy drive while booting up. If it
cannot detect one (either due to improper conguration or physical unavailability), it will ap-
pear an error message. Disabling this function, then POST will not detect the oppy.
► Intel VT-d Conguration/Trusted Computing
Press <Enter> to go to relative submenu.
► Boot Device Priority
This option is used to select the priority for boot devices. After pressing <Enter>, you can
select the device using the Up/Down arrow keys, and change the device priority using <+> or
<->; you can exit this menu by pressing <Esc>.
► Hard Disk Drives
This option is used to specify the boot priority sequence from available hard disk drives.
► Removable Drives
This option is used to specify the boot priority sequence from available removable drives.
