Create RAID 1

1. Select “1.Create RAID Volume” from the main menu and press <Enter>.

2. In "Name" item, you can input a device name for the RAID1 system and press

<Enter> to apply it. Here, we name it as TryRAID1 to replace the default Volume0.

3. In “RAID Level” item, you can use Up or Down arrow key to make a selection.

Select RAID1 (Mirror) and press <Enter>.

Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5

Enter a unique volume name that has no special characters and is

16 characters or less.

Intel(R) Rapid Storage Technology - Option ROM - 9.5.0.1021

[ CREATE VOLUME MENU ]

[ HELP ]

Name:

RAID Level:

Disks:

Strip Size:

Capacity:

Sync:

Volume0

RAID0(Stripe)

Select Disks

128KB

0.0 GB

N/A

Create Volume

TryRAID1

[↑↓]-Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select

Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5

RAID1: Mirrors data (redundancy).
