Fault status indicated by indicator:
Fault
S
SOC(LED4-1)
Under voltage fault
■
/
/
/
●
Over voltage fault
■
/
/
●
/
Over temperature fault
■
/
/
●
●
Under temperature fault
■
/
●
/
/
Discharge over current
■
/
●
/
●
Charge over current
■
/
●
●
/
Reserve
■
/
●
●
●
Parallel addressing failure
■
●
/
/
/
Pre-Charge failed
■
●
/
/
●
Short circuit Protection
■
●
/
●
/
AFE communication failed
■
●
/
●
●
Module addressing failed
■
●
●
/
/
Internal communication failed
■
●
●
/
●
Power parallel failure
■
●
●
●
/
PCS communication failed
■
●
●
●
●
HVB FUSE fault
●
/
/
/
●
Current sampling fault
●
/
/
●
/
Module not match
●
/
/
●
●
Internal total voltage sampling failed
●
/
●
/
/
Temperature sampling failed
●
/
●
/
●
Relay adhesion
●
/
●
●
/
Relay Not Close
●
/
●
●
●
Relay drive failed
●
●
/
/
/
Cell "0V" fault
●
●
/
/
●
Temperature high permanent failed
●
●
/
●
/
The Single voltage high permanently failed
●
●
/
●
●
SOH low protection
●
●
●
/
/
AFE failed（UV/OV/UT/OT）
●
●
●
/
●
Charger overvoltage
●
●
●
●
/
Other fault
●
●
●
●
●
