7. Commissioning
There are five LED indicators to show its operating status.
Different symbols indicate different flashing modes, and the explanation is as follows:
Symbol
Status
■
LED flash display (on: 0.5S,off: 0.5S )
/
LED off display
●
LED on display
SOC status indicated by indicator:
SOC
Status
S
SOC(LED4-1)
100% ≥ SOC > 75%
Standby
■
●
●
●
●
75% ≥ SOC > 50%
■
/
●
●
●
50% ≥ SOC > 25%
■
/
/
●
●
25% ≥ SOC ≥ 0%
■
/
/
/
●
=100%
Charge
●
●
●
●
●
100% > SOC ≥ 75%
●
■
■
■
■
75% > SOC ≥ 50%
●
/
■
■
■
50% > SOC ≥ 25%
●
/
/
■
■
25% > SOC ≥ 0%
●
/
/
/
■
100% ≥ SOC > 75%
Discharge
●
●
●
●
●
75% ≥ SOC > 50%
●
/
●
●
●
50% ≥ SOC > 25%
●
/
/
●
●
25% ≥ SOC ≥ 0%
●
/
/
/
●
