FoxESS LV5200 - Page 17

15
2. RUN indicator Steady on: The device is powered off or the battery is faulty and cannot be charged or
discharged.
20%≤SOC≤40%
○
●
●
●
●
●
◐
40%≤SOC≤60%
○
○
●
●
●
●
◐
60%≤SOC≤80%
○
○
○
●
●
●
◐
80%≤SOC≤90%
○
○
○
○
●
●
◐
90%≤SOC≤100%
○
○
○
○
○
●
◐
Status
Description
Fault
ADC/AFE Fault
◐
●
●
●
●
○
○
High Voltage
Fault
●
◐
●
●
●
○
○
Low Voltage Fault
◐
◐
●
●
●
○
○
High
Temperature
●
●
◐
●
●
○
○
Low Temperature
◐
●
◐
●
●
○
○
Over Current
●
◐
◐
●
●
○
○
Temperature
Difference Alarm
◐
◐
◐
●
●
○
○
Leakage Fault
●
●
●
◐
●
○
○
