2) After pressing the power switch for 1s, all LEDs will be on and flashing, which indicates that the
battery is started normally. After pressing the start button for 3s, the battery will turn on the discharge
function.
7. Commissioning
There are seven LED indicators on the front of the battery packs to show its operating status.
Fault status indicated by indicator:
● Off
○ On
◐ Flash
1. The RUN indicator blinks and the ALARM indicator is off: The battery is running.
Status
Description
CHARGE
0%=SOC
●
●
●
●
●
●
◐
0%≤SOC≤20%
◐
●
●
●
●
●
◐
20%≤SOC≤40%
○
◐
●
●
●
●
◐
40%≤SOC≤60%
○
○
◐
●
●
●
◐
60%≤SOC≤80%
○
○
○
◐
●
●
◐
80%≤ SOC＜100%
○
○
○
○
◐
●
◐
SOC＝100%
○
○
○
○
○
●
◐
DISCHARGE
&
STAND BY
0%≤SOC≤20%
●
●
●
●
●
●
◐
