4. Product Information
LV5200 photovoltaic energy storage system is a 48V energy storage system based on
lithium-ion ferrous phosphate battery. It is equipped with a customized battery management system
(BMS), which is designed for energy storage applications of household photovoltaic power generation
users. In the daytime, the surplus power of photovoltaic power generation can be stored in the battery. At
night or when necessary, the stored energy can be provided to the electrical equipment, it can improve
the use efficiency of photovoltaic power generation, peak-load shifting, and provide emergency standby
power.
4.1 Battery Module Specifications
4.2 Battery Charge/discharge Curve
Current protection
Trigger
Recover
Battery charge
First level over current
COC
≥105A, Lasts 30s
≥60s: Recover
Second level over current
COC2
≥125A, Lasts 1s
≥60s: Recover
Battery discharge
First level over current
DOC
≥110A, Lasts 300s
≥60s: Recover
Second level over current
DOC2
≥125A, Lasts 30s
≥60s: Recover
Third level over current
SC
≥155A, Lasts 1s
≥60s: Recover
Specifications for Battery
Note
Battery module
LV5200
Nominal capacity (Ah)
100
0.5C, 25±2°C
Nominal voltage (Vdc)
51.2
Nominal energy (kWh)
5.12
Battery voltage range (Vdc)
43.2 - 57.6
Max. continuous discharging current (A)
100
Max. continuous charging current (A)
100
Recommended charging current (CC-CV) (A)
100
Charging cut off current
(constant current and constant voltage) (A)
5
Peak charging current (30s) (A)
105
Peak discharging current (30s) (A)
150
Cycle life
≥6000@25°C @90% DOD
Storage temperature (°C)
-20 - 50
Operating temperature range (°C)
Charge: 0 - 55
Discharge: -15 - 55
Discharge capacity (Ah)
0°C±2 @ 1C @ 80%
25°C±2 @ 1C @ 100%
45°C±2 @ 1C @ 96%
Energy density (wh / kg)
104
Ingress protection
IP21
Communication
RS485/CAN
Weight (kg)
49
Dimensions (W*H*D) [mm]
342*207*600
Protective class
I
