FPT F34TE1W - Page 55

Visually Visually
Visually
inspect inspect
inspect
turbocharger turbocharger
turbocharger
Hazardwarning
Beforestarting,makesureyouhavesuitablePPE(gloves,shoes,
glasses,overalls).
Failuretocomplywiththeseprescriptionscanresultintheriskof
seriousinjury
Onlyproceedwhentheengineisnotrunning.
•
Checkforanycracksontheturbocharger.
•
Visuallycheckthattherotorsoftheturbine(6) (6)
(6)
andthecompressor
(4) (4)
(4)
andtherelativeinletandoutletpipesarenotcloggedordamaged.
Replaceiftheyare.
•
Checkthatnoneofthebladesarebentordamagedintherotorsof
theturbine(6) (6)
(6)
andthecompressor(4) (4)
(4)
.
•
Checkthetighteningofthe󰘰ttings(1) (1)
(1)
,(5) (5)
(5)
andcarryoutavisualin-
spectiontocheckforanyoilleaks.
•
Intheeventofanyoilleaks,replacethegasketsofthe󰘰ttings(1) (1)
(1)
,
(5) (5)
(5)
.
•
Checkthattherearenodepositsofsootbetweentheintakemanifold
andtheturbocharger.Replacetheturbochargergasketifnecessary.
•
Checktheturbochargergasketforanysignsofruptureordamage
andreplaceitifnecessary.
•
Checkthewastegateactuator(5)isfullytightened,lubricatedand
notdeformed.
•
Checkthatthewastegatevalvepipes(3) (3)
(3)
arenotcloggedordam-
aged,otherwisereplacethem.Carryoutavisualcheckandcheck
foranyairleaks.
54
