CONTROLS & SETTINGS
Power On/Off Switch
NOTICE
NEVER turn the Power Switch OFF when the unit is
in use! Doing so may result in spoilage and loss of
stored food products.
The 2-Drawer Combo Freezer/Cooler is provided with
a main power ON/OFF switch, mounted to the front
of the unit, above the two refrigerated drawers (Fig. 7).
Fig. 7
Factory Preset Temperature and
Adjustable Range
The temperatures for the 2-Drawer Combo Freezer/
Cooler are preset at the factory. The preset tem-
peratures are recommended for normal operation. If
needed, the temperatures can be adjusted. The fac-
tory presets and adjustable ranges are shown in the
following table (Table 2).
MODULE
FACTORY PRESET
TEMPERATURE/
CONTROL
SETTING
ADJUSTABLE
TEMPERATURE RANGE
Upper
(Freezer)
Drawer
-5° F (-20.5° C)
0° to -10° F
(-18° to -23° C)
Lower
(Refrigerator)
Drawer
37.5° F (3° C)
34° to 40° F
(1° to 4° C)
Table 2
Freezer/Cooler Temperature Adjustment
To adjust the temperatures of the unit:
1. Locate the appropriate temperature controller on
the front of the unit (Fig. 8).
Fig. 8
FREEZER
CONTROLLER
REFRIGERATOR
CONTROLLER
1. Press SET (Fig. 9).
Fig. 9
2. Press SET again. The current setpoint is displayed.
Press the UP and DOWN arrow buttons to adjust
the temperature setting (Fig. 10).
Fig. 10
3. Press the POWER button twice to save the new setting.
The current temperature will be displayed (Fig. 11).
Fig. 11
4. Monitor the unit to verify that it reaches the
desired operating temperature.
