Franke DC 2200 - PROGRAM BUTTON CHECK MODE; MALFUNCTION INDICATION CODE ER 10

10
6.1 programme button check mode (only for checking)
1. Press buttons
0
,
-
and
+
simultaneously for 5 sec’s. 88/88 appears on
display.
2. Press the program button to be checked. On display you can see
(when button 4 pressed e.g.)
4F/1 = sub display
4 = button 4 (1-5)
F = fan
1 = speed
Press button +
4C/60 appears on display
4 = button 4
C = temperature
60 = selected temperature (range 20-90
0
C)
Press button +
4t/30 appears on display
4 = button 4
t = drying time
30 = selected time (range 10-99 min)
Press button + until 88/88 appears. Now you can check the program button
you want. When, for example, 2F/0 appears there is no program restored.
3. After the programe checking you can start operating mode by switching
off and on the main power and the drying cabinet is ready to use.
6.2. Malfunction indication code Er 10
If a fault occurs all the drying cabinet functions will stop and on the digital display
panel will show Er + no. and also a red signal lamp will flash on the panel.
The system can be reset by switching the cabinet mains power switch off and on
again. CALL FOR AN ENGINEER.
Er No Fault Reason / Action required
Er10 Overheating protector has gone off
position.
Find the reason why this happened
- does the fan rotate
Er4
or
Er5
Temperature sensor in the drying
chamber does not function.
Check the connections; change the
temperature sensor
