FR
2
25
CARACTERISTIQUES
Encombrement
Min.
500mm
Min.
650mm
Composants
Réf. Q.té Composants de Produit
1 1 Corps Hotte équipé de:Commandes, Lumière,
Groupe Ventilateur, Filtres
8 1 Grille orientée Sortie de l ’Air
9 1 Flasque de Réduction ø 150-120 mm
20 1 Profil fermeture
Réf. Q.té Composants pour l ’installation
12a 4 Vis 4,2 x 44,4
12b 2 Vis 4,2 x 12,7
12e 2 Vis 2,9 x 9,5
Q.té Documentation
1 Manuel d’instructions
12b
