19011739 - Rev. A - November 30, 20185
KEY COMPONENTS
Overview
The High Capacity Meat Freezer (HCMF-P) is designed
for use at the kitchen grill station. The freezer provides
quick and easily access storage to frozen proteins.
The HCMF-P features stainless steel surface, three
shelves for boxed product, a digital temperature
controller for monitoring the current temperature of
the unit, and removable panels to allow access to
internal refrigeration components for maintenance.
The HCMF-P is available in both 18" and 30" models.
For instructions in this manual that apply to both
models, the 30" model will be shown.
1 2 3 4
5 6
8 9 10
7
Fig. 1
ITEM PART NAME QTY
1 Roll-Back Lid 1
2 Digital Temperature Controller 1
3 Front Louvered Access Panel 1
4 Bracket for Disposable Gloves 1
5 Locking Casters 4
6 Front Loading Door (shown hinged right) 1
7 Front Loading Door Gasket 1
8 Power ON/OFF Switch 1
9 Power Cord 1
10 Grill Tool Shelf 1
Table 1
