INSTALLATION
STEP 5
Turn top-right hinge upside-down and install to bottom-
left position using pre-installed screws (Fig. 12).
Fig. 12
STEP 6
Turn front-loading door upside-down. Place door onto
bottom-left hinge (Fig. 13).
Fig. 13
STEP 7
Continue to support door. Turn bottom-right hinge
upside-down and install to top-left position using pre-
installed screws (Fig. 14). Confirm that door opens
smoothly and that door gasket seals fully against
freezer compartment.
Fig. 14
STEP 8
Reinstall glove bracket, reversing steps outlined in
Step 1 (Fig. 15).
Fig. 15
