Franke Minerva 3-in-1 User Manual

EN
Installation instructions for push fitting
Installing the push fitting

Push the hose into the push fitting (fig. 2A).

Pull the hose carefully up and down and check
whether it is fitted securely (fig. 2B).
2A 2B
Remove the push fitting

Push in the ring on the push fitting (fig. 1C).

Pull the hose out of the push fitting (fig. 1D).
2C 2D
Icon legend
Product information
Scope of Delivery
Montage
Tooling Equipment
Do not use tools
Measure
Drill
Screw
Spanner
Cut
Tighten finger-tight
Check push fitting
Warning Sign / Caution / Hazard
Inspect
Determine position
Open
Close
Discard
Do not / Forbidden result
Do, OK! / Result
Installation step successfully completed
url / video link

Franke Minerva 3-in-1 Specifications

General

Voltage	230V
Power Supply	Electric
Power Consumption	1.5 kW
Capacity	4 liters
Tank Capacity	4 Litres
Water Pressure	0.5-6 bar
Material	Brass (tap), Stainless Steel (tank)
